3M 1558B Black 3M Electric Insulation Tape Flame Retardant Tape Acetate Cloth Tape For Battery Fixed Insulation

Brand Name:3M
Model Number:1558
Adhesive:Acrylic
Adhesive Side:Single Sided
Adhesive Type:Pressure Sensitive
Design Printing:No printing
Material:acetate cloth
Feature:Heat-Resistant
Use:MASKING
SIZE:Customized
Thickness:0.18mm

3M 1558B Black 3M Electric Insulation Tape Flame Retardant Tape Acetate Cloth Tape For Battery Fixed Insulation

3M 1558B Acetate Cloth Tape is made with black insulation cloth as the substrate and coated with a layer of acrylic pressure sensitive adhesive. This tape is very soft, easy to operate, and has high viscosity and tensile strength, providing insulation and protection, and can be flame retardant.





Application

This product is particularly suitable for internal insulation, binding, core, outer layer, and inter line insulation of deflection coils, as well as coil fixation, or computer wiring harness insulation that requires wear resistance and insulation protection, TV screen fixation, etc.

We can offer professional die cutting service according to customer’s request or drawing (any shape and any size) with above cutting machines. If any question, please do not hesitate to contact with us.





Our Factory Competitive Advantages:

Well Competitive Prices and High Quality Control.
Prompt Delivery.
Earth-friendly Products.
In a Variety of Design.
Small Order Acceptable.
OEM Accepted.

Roll Size: 3″ paper or plastic core;tape width: 2mm -1200mm; standard width: 1200mm, standard length: 50M.

OEM Size: Special length, thickness or combinations can be supplied per customer’s request. Products can be supplied in roll, tape, sheets or shapes per customer’s request. Only you provide the CAD drawing, we can die cut any size for you.

Shelf Life: To obtain best performance, use this product within 12 months from date of delivery and store under normal conditions of 60 ºC to 80ºF (16 ºC to 27ºC) and 40 to 60% R.H. in the original carton.

If the 3M 1558B Black 3M Electric Insulation Tape Flame Retardant Tape Acetate Cloth Tape For Battery Fixed Insulation to your requirement, please be free to buy the quality products made in China with our professional manufacturers and suppliers in China. We are equipped with a production factory to serve you.



Application

This product is particularly suitable for internal insulation, binding, core, outer layer, and inter line insulation of deflection coils, as well as coil fixation, or computer wiring harness insulation that requires wear resistance and insulation protection, TV screen fixation, etc.

We can offer professional die cutting service according to customer’s request or drawing (any shape and any size) with above cutting machines. If any question, please do not hesitate to contact with us.
Product Name
3M 1558B Black 3M Electric Insulation Tape Flame Retardant Tape Acetate Cloth Tape For Battery Fixed Insulation
Adhesive Type
Acrylic
color
black
Temperature resistance
130℃
Adhesion to 304 steel plate
30N/100mm
Features
• Good adhesion and superior anti warping performance

• Excellent shape and softness
• No burrs after slitting

Thickness
0.18mm
