3M 9713YXZ導電性両面テープを交換してください

FOB価格:$ 1.8- $ 1.93平方メートル
最小注文数量:1000平方メートル
供給能力:15000平方メートル
港:深セン、中国
支払い条件:T / T、L / C、Paypal、ウエスタンユニオン
納期:約10-15日

3M 9713YXZ導電性両面テープを交換してください

XST-210 Electrically Conductive Double Side Tape provides a better way for applications requiring excellent conductivity. Besides, XST-210 XYZ Electrically Conductive Double Sided Tape is made of a unique PSA to assure the adhesion to many kinds of substrate such as conductive fabric, aluminum foil, copper foil and so forth.

 Features:

  • Offer wide range of usage and service temperatures.
  • Excellent electrically conductive performance, XYZ conductivity.
  • Supplied on a removable liner for easy handling and die-cutting.
  • Thinner for avoiding remaining adhesive residual after slitting.

パッケージの詳細:

Export standard packing for XST-210 Electrically Conductive Tape. (If customers have special requirements, we also can make accordingly.)

私たちの工場の競争上の優位性:

  • 競争力のある価格と高品質管理
  • 迅速な配達
  • 地球にやさしい製品
  • さまざまなデザインで
  • 少量注文可
  • OEM承認済み

ロールサイズ:3インチの紙またはプラスチックコア;テープ幅:2mm -1200mm; 標準幅:1200mm、標準長さ:50M

OEMサイズ:お客様のご要望に応じて、特別な長さ、厚さ、または組み合わせを提供できます。製品は、お客様のご要望に応じてロール、
テープ、シート、または形状で提供できます。CAD図面を提供する場合にのみ、任意のサイズのダイカットを行うことができます。

貯蔵寿命:最高の性能を得るには、納品日から12か月以内にこの製品を使用
てください。



If the Replace 3M 9713 YXZ Electrically Conductive Double Side Tape to your requirement, please be free to buy the quality products made in China with our professional manufacturers and suppliers in China. We’re equipped with a productive factory at your service.



  • EMI shielding applications in mobile phone, notebook, PC and other electronic products.
  • EMI shielding applications in connector, FFC and wire stock etc..
  • Die cut pieces and laminate.
Properties No.XST-210
接着剤タイプ 400
Carrier Type N.A.
Release Liner Release Liner
Roll Length
Standard
Maximum
20m/50m
50m
Roll Width 1080mm
接着剤の厚さ 0.1mm±10%
Adhesive Color グレー
Slitting Tolerance ±0.4mm
180° Peel Adhesion
(PSTC-101) (N/Inch)
>11.76
Electrical Resistance
(Microhm Meter) (Ohm)
<0.1
Temperature Tolerance
Long Term ℃ (℉)
Short Term ℃ (℉)
120 (248)
180 (356)
保持力
(PSTC-7)(Hr)
(1Kg/inch) (25℃)
>18
Initial Tack (PSTC-6 #14)(mm) <200
Temperature Range of Usage -20℃~120℃

Storage and Shelf Life:

Store in original cartons at 23 ±5℃ and 60%±10% relative humidity in order to obtain the best performance, besides using these products within 18 months from the date of manufacture.

Important Notice:

  • This document is the property of XST tape. Please consult with us before using it.
  • This document for any purpose other than that for which it was intended.
  • The data provided herein are measurement only and are not guaranteed. Please make sure the product is capable of the application before actually tempting to put it to use.
  • Users assume all risk and liability associated with such use.
