PET Insulation Transformer Mylar Tape

Mylar Insulation Tape, it is made of polyester film as backing, and single side coated with acrylic adhesive. designed for electrical use to prevent leakage, since the insulation tape is of good insulation property, fire retardant, weather resistant and other features.

PET Insulation Transformer Mylar Tape Descriptions:

Mylar Insulation Tape, it is made of polyester film as backing, and single side coated with acrylic adhesive. designed for electrical use to prevent leakage, since the insulation tape is of good insulation property, fire retardant, weather resistant and other features.



Features:

• High temperature resistance
• Solvent proof
• Flame resistance
• Electrical insulation



Our Factory Competitive Advantages:

Well Competitive Prices and High Quality Control.
Prompt Delivery.
Earth-friendly Products.
In a Variety of Design.
Small Order Acceptable.
OEM Accepted.

Roll Size: 3″ paper or plastic core;tape width: 2mm -1200mm; standard width: 1200mm, standard length: 50M.

OEM Size: Special length, thickness or combinations can be supplied per customer’s request. Products can be supplied in roll, tape, sheets or shapes per customer’s request. Only you provide the CAD drawing, we can die cut any size for you.

Shelf Life: To obtain best performance, use this product within 12 months from date of delivery and store under normal conditions of 60 ºC to 80ºF (16 ºC to 27ºC) and 40 to 60% R.H. in the original carton.

If the pet insulation transformer mylar tape caters to your requirement, please be free to buy the quality products made in China with our professional manufacturers and suppliers in China. We're equipped with a productive factory at your service.

Applications:
• Mylar insulation tape is widely used in the insulation package for electronics partssuch as transformers, motors, capacitors, energy saving lamp, micro-engine,capacitor and other electrical components.

Specifications:

Product Code Xinst1101 Xinst1102
Name  PET insulated tape  PET insulated tape
Thickness(mm) 0.06 0.1
Adhesive Acrylic Acrylic
Backing PET PET
Color Yellow/white/black/red/green Yellow/white/black/red/green
Liner No No
Short-term temperature 150 150
Long-term temperature 130 130
